Table 5-5 Settings of the DIP switches
DIP Bit Functions Setting
Four least
significan
t bits (1,
2, 3, and
4)
Define the
monitoring address
of the PMU.
The bit 1 indicates ON, and the bit 0 indicates OFF. Bits
1 to 4 are set to 1100 by default before delivery.
Four most
significan
t bits (5,
6, 7, and
8)
Reserved for future
use.
The bit 1 indicates ON, and the bit 0 indicates OFF. Bits
5 to 8 are set to 0000 by default before delivery.
BTS3900C (Ver.C)
Hardware Description 5 BTS3900C Monitoring System
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
115
