Huawei BTS3900C User Manual

X1 End (Pin
of the
Standard
AISG Male
Connector)
X2 End (Pin
of the
Standard
AISG
Female
Connector)
Color Type Description
Orange
X1.3 X2.3 White and green Twisted pair RS485 B
X1.5 X2.5 Green RS485 A
X1.6 X2.6 White and brown Twisted pair +24 V
Brown
BTS3900C (Ver.C)
Hardware Description 7 BTS3900C Cables
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
175
