d. Configure the working mode of a LAN port.
a. In the navigation tree, choose LANDevice > LAN Interface 1 > LAN
Interface.
b. Select LAN Interface, right-click, and choose Add. Add LAN Ethernet
Configuration 2 and LAN Ethernet Configuration 3.
c. Select LAN Ethernet Configuration 3 and set LAN Port two three-port
enable to enable. This indicates that LAN 3 works in Layer 3 mode.
NOTE
l If LAN Port two three-port enable is disable, the LAN port works in the Layer 2
mode.
l If LAN Port two three-port enable is enable, the LAN port works in the Layer 3
mode.
LAN Port two three-port enable is defaulted to disable.
By default, the system has one LAN Ethernet Configuration 1 node. To add multiple
nodes, select LAN Interface, right-click, and choose Add from the shortcut menu.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
199
