1. In the navigation tree on the left, choose WAN > WAN Configuration. In the pane
on the right, click New. In the dialog box that is displayed, set Mode to Bridge, as
shown in Figure 5-12.
Figure 5-12 WAN Configuration - bridge
2. Click Apply to apply the configuration.
Table 5-2 describes the parameters related to the WAN in bridge mode.
Table 5-2 Parameters related to the WAN in bridge mode
Parameter
Description
Enable Indicates whether to enable the WAN
connection.
Service List Indicates the service type of the WAN
interface. It is always set to INTERNET.
VLAN ID Indicates the VLAN ID. It ranges from 1 to
4094.
The VLAN ID must be the same as the
CVLAN ID on the OLT.
802.1p Indicates the 802.1p value. It ranges from
0 to 7.
MultiCast VLAN ID The multicast VLAN ID ranges from 1 to
4094.
The multicast VLAN ID must be the same
as the multicast VLAN ID on the OLT.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 5 Web Page Reference
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
309
