a. In the Main Topology, double-click the required OLT in the Physical Root
navigation tree; or right-click the required OLT and choose NE Explorer from
the shortcut menu.
b. Choose GPON > GPON Management from the navigation tree.
c. On the GPON UNI Port tab page, set the filter criteria to display the required
GPON UNI ports.
d. In the information list, right-click GPON UNI port 0/2/1 and choose Enable
ONU Auto Find from the shortcut menu.
e. Select the ONU tab page. Click the Auto Discover ONUs tab.
f. In the window that is displayed, select 6877687714852901 as the ONU record
and click Confirm.
– Name: ONT
– ONU ID: 0
– ONU Type: ONT
– On the Basic Parameters tab page, set the parameters.
– Line Profile: FTTx (click
next to Line Profile and select the line profile
named FTTx in the dialog box that is displayed)
– Service Profile: FTTx (click
next to Service Profile and select the
service profile named FTTx in the dialog box that is displayed)
– Authentication Mode: SN
– Terminal Type: 247
– Software Version: V1R002C06 (or V1R002C07)
g. Click OK.
l Configure the voice service.
The prerequisite for performing operations in the navigation tree is to navigate to the NE
Explorer of the OLT. To navigate to the NE Explorer of the OLT, do as follows: In the
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
70
