Main Topology, double-click the required OLT in the Physical Root navigation tree; or
right-click the required OLT and choose NE Explorer from the shortcut menu.
NOTE
Some voice parameters cannot be configured on the NMS but can be configured by importing an XML
configuration file. For details about how to import an XML configuration file, see 3.6.2 Operation Guide
on the XML Configuration File (on the U2000).
1. Configure a service VLAN on the OLT side.
A service VLAN is the VLAN used for the voice service.
a. Choose VLAN from the navigation tree.
b. On the VLAN tab page, right-click and choose Add from the shortcut menu.
c. In the dialog box that is displayed, set the parameters.
– VLAN ID: 200
– Type: Smart VLAN
d. Click Next.
e. Click the Upstream Port tab and add upstream port 0/19/0 as the upstream port
of the VLAN.
f. Click Done.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
71
