FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2.2 Typical Configuration (Single-Phase 220 V Power
System)
Single-Cabinet Solution
Figure 2-1 24 U Converged Cabinet
Table 2-1 Typical configuration 1
Cabinet dimensions (W x D x H)
600 mm x 850 mm x 1200 mm
UPS2000-G, battery pack
(optional)/external battery (optional),
PDU5000, and rPDU (referred to as
PDU2000 in the following text)
ECC800e, temperature and humidity sensor
(T/H sensor), door status sensor, smoke
detector, water sensor, infrared remote
control module (optional), GSM modem
(optional)
