FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
57
Indicator
Color
Silk
Screen
Status
Description
intervals
Blinking at
long intervals
The networking succeeds.
Alarm
Red
ALM
Off
The BIM is not faulty.
Steady on

The BIM is faulty.

Communication with the CIM
times out.

No network is connected. (The
BIM is waiting to connect to a
network.)
Blinking at
super short
intervals

Network parameters are being
cleared.

The BIM is blinking.

If an indicator blinks at long intervals, it is blinking on for 1s and then off for 1s.

If an indicator blinks at super short intervals, it is blinking at 10 Hz, that is, on for 0.05s and then off
for 0.05s.
Networking Switch
Table 3-41 Networking switch description
Name
Definition
Function
Button pressing
Press the button for less
than 5 seconds.
Searches for and joins a network if there is no
network. Initializes the network parameters if
there is a network.
Button holding
down
Hold down the button
for more than 5
seconds.
Clears the current network and resets the
wireless module; disconnect the network.
3.4.8 Water Sensor
A water sensor detects water on the floor in real time and generates an alarm when water is
detected.
