Figure 3-28 Water sensor
Table 3-42 Water sensor technical specifications
Item
Specifications
Operating voltage
12 V DC (9–16 V DC)
Insulation resistance
> 500 megohms
Operating temperature
–20°C to +70°C, 10%–80% RH
(non-condensing)
Storage temperature
–40°C to +80°C, 10%–80% RH
(non-condensing)
Reliability
Failure rate: 800 fits
Power consumption
< 1 W
3.4.9 (Optional) Pad
Figure 3-29 Pad
The pad is a capacitive screen which supports multi-touch.
