FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2.3 Typical Configuration (Dual-Live Wire 208 V Power
System)
Single-Cabinet Solution
Figure 2-7 42 U Converged Cabinet
Table 2-7 Typical configuration 1
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
UPS2000-G, battery pack
(optional)/external battery (optional),
PDU5000, PDU2000, and transformer
ECC800e, T/H sensor, camera (optional),
VCN500 (optional), door status sensor,
smoke detector, water sensor, pad
(optional), WiFi converter (optional),
infrared remote control module (optional),
GSM modem (optional), NetEco (optional),
and LAN switch (optional)
