3.2.2.3 10 kVA UPS
Figure 3-9 UPS2000-G
Table 3-10 10 kVA UPS technical specifications
Item
Specifications
Rated capacity
9 kVA
Maximum input current
48 A
Number of phases
Dual-live wire
Input power factor (full load)
> 0.99
input frequency
Rated frequency: 50 Hz/60 Hz
Range: 40–70 Hz
THDi
< 5%
Output voltage
208 V
Tolerance: ±1%
Output frequency

Normal mode: 50 Hz/60 Hz (±6 Hz)

Battery mode: 50 Hz/60 Hz (±0.05%)
Output power factor
0.9
Efficiency
94.5%
Communications port (optional)
USB/RS485
Dimensions (W x D x H)
430 mm x 615 mm x 86 mm
Weight
16 kg
Noise
< 55 dB
