Huawei FusionModule500 Manual

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
60
Table 3-44 WiFi converter technical specifications
Item
Specifications
Wireless standard
IEEE 802.11n, IEEE 802.11g, and IEEE
802.11b
Network bandwidth

11n: up to 150 Mbit/s

11g: up to 54 Mbit/s

11b: up to 11 Mbit/s
Frequency band
2.4–2.4835 GHz
Wireless transmission power
20 dBm
Supported operating system
Windows 2000/XP/Vista/Linux/Windows 7
Dimensions (L x W x H)
20 mm x 14 mm x 6 mm
Port
USB 2.0 Hi-speed connector
Voltage range
5.0 V DC ±5%
Operating temperature
–20°C to +70°C
Storage temperature
–40°C to +90°C
Humidity
10%–90% RH (non-condensing)
Storage humidity
5%–90% RH (non-condensing)
Power
< 0.8 W
3.4.11 (Optional) VCN500
Figure 3-31 VCN500
Table 3-45 VCN500 technical specifications
Item
Specifications
Video input
A single VCN500 supports the access from a maximum of 32
cameras and the maximum access bandwidth of 160 Mbit/s.
Video transfer
A single VCN500 supports the video transfer from 32 cameras or of
160 Mbit/s.
