FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
23
Item
Specifications (10
kVA UPS)
Specifications (6
kVA UPS)
Specifications (3
kVA UPS)

100 Ah/12 V

100 Ah/12 V
Surge protection
Level D SPD
(differential
mode/common
mode: 5 kA)
Level D SPD
(differential
mode/common
mode: 5 kA)
Level D SPD
(differential
mode/common
mode: 5 kA)
3.2.1.2 3 kVA UPS
Figure 3-3 UPS2000-G
Table 3-3 3 kVA UPS technical specifications
Item
Specifications
Rated capacity
3 kVA
Maximum input current
19 A
Number of phases
1
Input power factor (full load)
> 0.99
input frequency
Rated frequency: 50 Hz/60 Hz
Range: 40–70 Hz
Total distortion of the input current
waveform (THDi)
< 5%
Output voltage
220 V/230 V/240 V
Tolerance: ±1%
Output frequency

Normal mode: 50 Hz/60 Hz (±6 Hz)

Battery mode: 50 Hz/60 Hz (±0.05%)
Output power factor
0.9
