Huawei FusionModule500

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
43
Figure 3-16 Smoke detector
Table 3-24 Smoke detector technical specifications
Item
Specifications
Operating voltage
9–27 V
Alarm current
< 20 mA
Indication
Monitoring: The red indicator blinks once
every 3 to 8 seconds.
Alarm reporting: The red indicator is steady
on.
Operating temperature
–10°C to +55°C
Ambient humidity
≤ 95% RH
Dimensions (L x W x H, including the base)
75 mm x 51 mm x 31 mm
Weight
50 g
