Sensor Description Component
RTC Battery RTC battery status. An
alarm is generated when
the voltage is lower than
1 V.
RTC battery
PCIE Status PCIe status PCIe cards
ACPI State ACPI status Mainboard
Power Button Power button pressed
state
Mainboard and power
button
Watchdog2 Watchdog Mainboard
Mngmnt Health Management subsystem
health status
Management modules
UID Button UID button status Mainboard
PwrOk Sig. Drop Voltage dip status Mainboard
PwrOn TimeOut Power-on timeout Mainboard
PwrCap Status Power capping status Mainboard
HDD Backplane Entity presence Drive backplane
HDD BP Status Drive backplane health
status
Drive backplane
Riser1 Card Entity presence Riser card
SAS Cable Entity presence SAS cable on the
mainboard
FAN N Presence Fan presence Fan module N
N indicates the fan
module number. The
value ranges from 1 to 5.
RAID Presence RAID controller card
presence
RAID controller card
PS Redundant Redundancy failure due
to PSU removal
PSUs
NIC# Status NIC fault diagnosis
health status
LOM
PS N Status PSU status PSU N
N indicates the PSU
number. The value is 1 or
2.
