Sensor Description Component
PS N Fan Status PSU fan status PSU N
N indicates the PSU
number. The value is 1 or
2.
PS N Temp Status PSU presence PSU N
N indicates the PSU
number. The value is 1 or
2.
DISK N Drive status Drive N
N indicates the drive slot
number. The value
ranges from 0 to 27.
M2Disk N Status of the M.2 drives
on the riser card
M.2 drives on the riser
card
Port N Link Down LOM LOM
PCIe RAID$ Temp PCIe RAID controller card
temperature
PCIe RAID controller card
RAID Temp RAID controller card
temperature
RAID controller card
RAID Status RAID controller card
health status
RAID controller card
RAID PCIE ERR RAID controller card
fault diagnosis health
status
RAID controller card
IB$ TEMP IB adapter temperature IB adapter
RAID Card BBU RAID controller card BBU BBU supercapacitor of
RAID controller card
PS$ Inlet Temp PSU air inlet
temperature
PSUs
OCP1 OP Temp OCP 2.0 mezzanine card
optical module
temperature
OCP 2.0 mezzanine card
optical module
temperature
OCP1 Temp OCP 2.0 mezzanine card
chip temperature
OCP 2.0 mezzanine card
chip temperature
