Huawei Quidway S3526 User Manual

Installation Manual
Quidway S3526 Ethernet Switch Chapter 1 Overview
1-2
ICP
ICP
GSR
MAN
backbone
L3
Data
center
S3026
S3026
S2403/
S3026
S3526
Core layer
devices
Convergence layer
devices
Access layer
devices
in a residential quarter or a building
Desk-top access layer
devices
Local service
center
ICP
ICP
GSR
MAN
backbone
L3
Data
center
S3026
S3026
S2403/
S3026
S3526
Core layer
devices
Convergence layer
devices
Access layer
devices
in a residential quarter or a building
Desk-top access layer
devices
Local service
center
Figure 1-1 Networking of Ethernet access
1.2.2 Networking of VDSL Access in Broadband Residential Quarter
In the networking application of a broadband residential quarter, S3526 Ethernet
Switch can be downstream connected to VDSL users via S3026V switch and can be
upstream connected to core layer-3 switches of the MAN backbone via GE expansion
module slots.
