Huawei Quidway S3526 - Networking of Large Enterprise and Campus

Installation Manual
Quidway S3526 Ethernet Switch Chapter 1 Overview
1-4
Internet/Enterprise network
server
server
PCPCPC
PC
PC
GE(1000M)
FE(100M)
FE(100M)
S2403
S3026
S3526
Figure 1-3 Networking of medium and small-sized enterprises and the branches of large enterprises
1.2.4 Networking of Large Enterprise and Campus
In large-scale enterprise network and the campus network, S3526 are located in the
convergence layer, attached with several layer-2 Ethernet switches such as Quidway
S3026 Ethernet Switch. In the upstream direction, S3526 switches are connected to
the core layer-3 switches via the GE expansion module slots. Thereby, it offers a
complete enterprise networking solution, which provides 1000M bandwidth to
backbone network and 100M bandwidth to desktop users
