Installation Manual
Quidway S3526 Ethernet Switch Chapter 2 Specifications and Features
2-2
Table 2-1 Front panel indicators of S3526 Ethernet Switch
Indicator Panel indication Status Description
On The switch is powered on.
Power indicator POWER
Off The switch is powered off.
On The connection is normal.
Off No connection is being made.
Link/Active
(Orange)
Blinking The data is being sent or received.
On 100Base-TX operating mode
10Base-T/100Base-TX
Speed (Green)
Off 10Base-T operating mode
Note:
The 10Base-T/100Base-TX RJ-45 connector of S3526 Ethernet Switch supports auto sensing of
MDI/MDI-X.
2.2.2 Ethernet Interface
The Ethernet interface on the front panel uses the connector with indicators. The
connector type is of standard RJ-45. The attributes of the Ethernet interface are listed in
the following table.
Table 2-2 Attribute of 10Base-T/100Base-TX interface
Attribute S3526
Type of connector RJ-45
Number of interfaces 24
Functions
100Mbps full duplex
10M full duplex
MDI/MDI-X auto sensing
Cable and transmission distance
Category-5 twisted pair cabling. A maximum transmission distance of 100m
is supported.
Note:
For the appearance of RJ-45 connector and relevant description of MDI/MDI-X, see appendix A.
2.2.3 Console Port
S3526 Ethernet Switch provides a console port compliant with EIA/TIA-232
asynchronous serial standard. You can perform the switch configuration via this port.
