OSPF Process 1 with Router ID 4.4.4.4
Neighbors
Area 0.0.0.0 interface 192.168.1.4(Vlanif10)'s neighbors
Router ID: 1.1.1.1 Address: 192.168.1.1
State: Full Mode:Nbr is Slave Priority: 100
DR: 192.168.1.4 BDR: 192.168.1.3 MTU: 0
Dead timer due in 31 sec
Retrans timer interval: 5
Neighbor is up for 00:11:17
Authentication Sequence: [ 0 ]
Router ID: 2.2.2.2 Address: 192.168.1.2
State: Full Mode:Nbr is Slave Priority: 0
DR: 192.168.1.4 BDR: 192.168.1.3 MTU: 0
Dead timer due in 35 sec
Retrans timer interval: 5
Neighbor is up for 00:11:19
Authentication Sequence: [ 0 ]
Router ID: 3.3.3.3 Address: 192.168.1.3
State: Full Mode:Nbr is Slave Priority: 2
DR: 192.168.1.4 BDR: 192.168.1.3 MTU: 0
Dead timer due in 33 sec
Retrans timer interval: 5
Neighbor is up for 00:11:15
Authentication Sequence: [ 0 ]
NOTE
The DR priority on the interface is invalid after it is configured.
5. Restart OSPF processes.
On each Switch, run the reset ospf 1 process command in the user view to restart the OSPF
process.
6. Verify the configuration.
# Check the status of OSPF neighbors.
[SwitchD] display ospf peer
OSPF Process 1 with Router ID 4.4.4.4
Neighbors
Area 0.0.0.0 interface 192.168.1.4(Vlanif10)'s neighbors
Router ID: 1.1.1.1 Address: 192.168.1.1
State: Full Mode:Nbr is Master Priority: 100
DR: 192.168.1.1 BDR: 192.168.1.3 MTU: 0
Dead timer due in 35 sec
Retrans timer interval: 5
Neighbor is up for 00:07:19
Authentication Sequence: [ 0 ]
Router ID: 2.2.2.2 Address: 192.168.1.2
State: 2-Way Mode:Nbr is Slave Priority: 0
DR: 192.168.1.1 BDR: 192.168.1.3 MTU: 0
Dead timer due in 35 sec
Retrans timer interval: 5
Neighbor is up for 00:00:00
Authentication Sequence: [ 0 ]
Router ID: 3.3.3.3 Address: 192.168.1.3
State: Full Mode:Nbr is Slave Priority: 2
DR: 192.168.1.1 BDR: 192.168.1.3 MTU: 0
Dead timer due in 37 sec
Retrans timer interval: 5
Neighbor is up for 00:07:17
Authentication Sequence: [ 0 ]
# Check the status of an interface enabled with OSPF.
