HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
offers a maximum memory capacity of 16 GB.
Supports 1333 MHz or 1600 MHz UDIMMs.
Supports error checking and correction (ECC).
The MXUA0 implements intra-subrack switching and
inter-subrack expansion on the Base plane and eFabric
plane.
The panel provides two external 1GE Base ports and
two 40GE eFabric ports.
The Base plane provides one 1GE channel for each
service slot.
The eFabric plane provides 80 Gbit/s bandwidth for
each service slot.
There are Base and eFabric plane interconnect
channels between MXUA0s.
The SMM provides the following device management
functions:
Board management
− Detects the board temperature, voltage, and
power, implements power control, manages board
hot swap and reset, and monitors the operating
and health status.
− Supports out-of-band and remote management.
Subrack management
− Performs power supply monitoring, fan
management, and power distribution
management.
− Communicates with the baseboard management
controllers (BMCs) on service boards to manage
and control the service boards.
Supports one 600 GB 2.5-inch SAS disk.
The boards are hot-swappable.
Appearance
The MXUA0s are half-width boards and can be installed in front slots 2 and 5 in the F8002
subrack. Figure 1-28 shows an MXUA0.
