HUAWEI SE2900 Session Border Controller
Hardware Description
2 Other Accessories
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
91
Categor
y
Item
Specifications
System
configura
tion
paramete
rs
Power supply
DC: -48 V to -60 V/0.5 A
AC: 100 V/50 Hz/0.3 A to 240 V/50 Hz/0.3 A
RS422 communication
distance
100 m (328.08 ft)
RS232 communication
distance
80 m (262.46 ft)
Maximum number of
communication interfaces
5
Maximum remote alarm
confirm distance
30 m (98.42 ft)
Maximum distance of the
remote speaker (1W active
speaker)
30 m (98.42 ft)
2.2 Optical Module
Functions
An optical module provides optical-to-electrical and electrical-to-optical conversion functions.
It is connected to an optical fiber to transmit signals.
Appearance
Optical modules can be classified into the following types by encapsulation type: small
form-factor pluggable (SFP), enhanced SFP (eSFP), small form-factor pluggable plus (SFP+),
10-GB small form-factor pluggable transceiver (XFP), and quad small form-factor pluggable
plus (QSFP+). The optical module appearance varies according to the encapsulation type.
Figure 2-3 shows an SFP/SFP+ optical module. Figure 2-4 shows a QSFP+ optical module.
