HUAWEI SE2900 Session Border Controller
Hardware Description
3 Cables
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
113
Technical Specifications
The MPO/PC-MPO/PC-multi-mode optical cables comply with ITU G651 and GB/T 12357.
Table 3-9 lists the technical specifications of the MPO/PC-MPO/PC-multi-mode optical cable.
Table 3-9 Technical specifications of the MPO/PC-MPO/PC-multi-mode optical cable
Item
Specifications
Cable type
Optical cable component
Transfer mode
Multi-mode
Number and type of optical
connector I
MPO/PC
Number and type of optical
connector II
MPO/PC
Diameter of the optical fiber
core
50 um/125 um
Number of optical fiber cores
8
Outer diameter of an optical
cable
3.5 mm (0.14 in.)
Optical cable length
2 m (78.74 in.), 30 m (1181.1 in.) or 100 m (3937 in.)
Service life
200 times
3.2.6 High-Density Cable
Functions
A high-density cable is connected to a high-density port at one end, and provides one VGA
port, three USB ports, and one serial port at the other end for data transmission.
Appearance
Figure 3-17 shows a black high-density cable.
