Huawei SE2900 - Power Cables of the Alarm Box

HUAWEI SE2900 Session Border Controller
Hardware Description
3 Cables
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
104
Table 3-1 Technical specifications of the power and PGND cables for a subrack
Item
Specifications
Power cable
Power cable with OT terminals or dual-hole JG
terminals: 10 mm
2
(8 AWG)
AC power cable

AC power cable using the C13 SF and PI SM:
China, 250 V/10 A, 1 mm
2
, 10°C to 70°C, and
C13 SF and PI SM

AC power cable using the C13 AF and C14
SM: China/Europe, 250 V/10 A, 1 mm
2
, -20°C
to +105°C, and C13 AF and C14 SM
PGND cable
16 mm
2
(6 AWG)
3.1.2 Power Cables of the Alarm Box
Functions
The power cables are used for supplying power to the alarm box.
Table 3-2 lists the configuration of the power cables.
Table 3-2 Configuration of the power cables
Power
Supply
Quantit
y
Remarks
AC power
supply
1
The cable is configured only if system down notification is
required for the alarm box. If the length of the cable is not
sufficient, connector boards must be added. The boards are
provided by carriers. If carriers do not provide the connector
boards, the quantity of the required boards must be provided in
the survey report.
DC power
supply
1
DC power cable is recommended. An alarm box requires only
one power cable. The length of the cable cannot exceed 100 m
(328.08 ft).
Exterior
None.
Technical Specifications
Table 3-3 lists the technical specifications of the power cables of alarm boxes.
