HUAWEI SE2900 Session Border Controller
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 3-17 High-density cable
Technical Specifications
Figure 3-18 shows the pins at both ends of a high-density cable. Table 3-10 lists the technical
specifications of the high-density cable.
Figure 3-18 Pins at both ends of a high-density cable (unit: mm)
Table 3-10 Technical specifications of the high-density cable
Cable connector, MDR, 26-pin, male, cable
solder type, for OEM
Cable connector, D connector, 15-pin,
female connector, cable solder type, three
