HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
41
Silk
Scre
en
Meani
ng
State
State Description
Steady green
An indicator in the on state stands for the binary digit
1.
To set the subrack number, hold down the DIP button
for 6 seconds until the indicators enter the setting
mode, press the DIP button to set the subrack
number, and then hold down the DIP button for 6
seconds to complete the setting.
Binary numbers 000 to 111 indicate subrack numbers
0 to 7 respectively.
NOTE

The subrack number can be set only on the active SMM.
The standby SMM only supports indicator test mode.

If you do not press the DIP button within 30 seconds after
the indicators enter the setting mode, the indicators exit
the setting mode without saving the settings.

Each time you press the DIP button, the subrack number
increases by 1. The subrack number restarts from 0 after
it passes 7.
ACT
Networ
k port
indicat
or
Off
The port is not sending or receiving data.
Blinking yellow
The port is sending or receiving data.
LIN
K
Networ
k port
indicat
or
Green
The link is connected.
Off
The link is faulty or disconnected.
eFabr
ic
LAN
0/LA
N1
Indicat
or of
the
cascadi
ng port
of the
eFabric
plane
Off
The link is faulty or disconnected.
Steady green
The link is connected.
Blinking green
The port is sending or receiving data.
Base
LAN
0/LA
N1
Indicat
or of
the
cascadi
ng port
of the
Base
plane
Green off
The link is faulty or disconnected.
Steady green
The link is connected.
Yellow off
The port is not sending or receiving data.
Blinking yellow
The port is sending or receiving data.
In the cascading environment, if the MXUA0 GPC in the slave subrack is isolated, the GPC is powered
off, the OFL indicator is off, and the OFL button is unavailable.
