● Reserve enough clearance around the inverter and select an appropriate
installation angle to ensure sucient space for installation and heat
dissipation.
Figure 4-2 Installation space
The clearance at the bottom must meet the requirements on the bending radius of the
AC output power cable.
Figure 4-3 Installation angle
SUN2000-(175KTL-H0, 185KTL-INH0, 185KTL-H1)
User Manual 4 Installation
Issue 19 (2023-12-20) Copyright © Huawei Technologies Co., Ltd. 32
