Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
2 Overview
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Indicator
Status
Meaning
seconds.
Alarm/Maintenanc
e indicator
Alarm status
Blinking red at long
intervals (on for 1s
and then off for 4s)
A warning alarm is
generated.
Blinking red at short
intervals (on for 0.5s
and then off for 0.5s)
A minor alarm is
generated.
Steady red
A major alarm is
generated.
Local
maintenance
status
Blinking green at
long intervals (on for
1s and then off for
1s)
Local maintenance is in
progress.
Blinking green at
short intervals (on
for 0.125s and then
off for 0.125s)
Local maintenance fails.
Steady green
Local maintenance
succeeds.

Local maintenance refers to operations performed after a universal serial bus (USB) flash drive,
Bluetooth module, or USB data cable is inserted into the USB port of the SUN2000. For example,
local maintenance includes data import and export using a USB flash drive and connecting to the
SUN2000 app over a Bluetooth module or USB data cable.

If alarming and local maintenance happen concurrently, the alarm/maintenance indicator shows the
local maintenance state first. After the USB flash drive, Bluetooth module, or USB data cable is
removed, the indicator shows the alarm state.
SUN2000 Rear View
Figure 2-6 shows the SUN2000 rear view.

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
