Figure 7-5 Grid parameters (special user)
----End
Parameter List
No.
Parameter Description Remarks
1 Grid code Set this parameter based on the grid
code of the country or region where the
SUN2000 is used and the SUN2000
application scenario.
N/A
2 Output mode Indicates whether the SUN2000 output
has a neutral wire.
Supported by the
SUN2000-50KTL-M0
and SUN2000-60KTL-
M0 only.
3 PQ mode If this parameter is set to PQ mode 1,
the maximum active power equals the
maximum apparent power. If it is set to
PQ mode 2, the maximum active power
equals the rated active power.
4 Auto start upon
grid recovery
Species whether to allow the SUN2000
to automatically start after the power
grid recovers.
N/A
5 Grid connection
duration after
power grid
recovery
Species the waiting time for SUN2000
restart after the power grid recovers.
N/A
SUN2000-(50KTL, 60KTL, 65KTL)-M0
User Manual 7 Man-Machine Interactions
Issue 11 (2024-02-02) Copyright © Huawei Technologies Co., Ltd. 92
