Huawei SUN2000-50KTL-M0

To Next Page

To Previous Page

Type Tool

Install

ation

tools

Hammer drill

Drill bit (Ф14 mm

and Ф16 mm)

Insulated torque

socket wrench

Phillips insulated

torque screwdriver

(M4)

Flat-head insulated

torque screwdriver

(M4)

Wire stripper Flat-head

screwdriver

Head: 0.6 mm x 3.5

Rubber mallet

Utility knife Cable cutter Crimping tool

Model: UTXTC0005

or H4TC0003

manufacturer:

Amphenol

RJ45 crimping tool

Removal wrench

Model: H4TW0001;

manufacturer:

Amphenol

Vacuum cleaner

Multimeter (DC

voltage

measurement range

≥ 1100 V DC)

Marker
