Huawei SUN2000-6KTL-M1 User Manual

Indicators Status Remarks Description
Blinking red
and green
alternatively
Blinking at long
intervals (on for 1s
and then o for
1s)
No communication
with the SUN2000
– Remove and then
insert the Smart
Dongle.
– Check whether the
SUN2000 matches
the Smart Dongle.
– Connect the Smart
Dongle to another
SUN2000.
Check whether the
Smart Dongle is
faulty or the USB
port of the
SUN2000 is faulty.
----End
SUN2000-(3KTL-10KTL)-M1 Series
User Manual 6 Commissioning
Issue 17 (2024-01-12) Copyright © Huawei Technologies Co., Ltd. 82

Huawei SUN2000-6KTL-M1 Specifications

General

Max. Efficiency	98.4%
Rated AC Output Power	6000 W
Max. AC Apparent Power	6600 VA
AC Grid Frequency	50/60 Hz
Dimensions	525 x 470 x 146.5 mm
Weight	17 kg
Operating Temperature Range	-25°C to +60°C
IP Rating	IP65
Max. DC Voltage	1100 V
Start Voltage	200 V
European Weighted Efficiency	97.8%
Cooling Method	Natural Convection
Max. DC Power	9000 W
Nominal Output Voltage	230 V
