Huawei SUN2000-70KTL-C1 User Manual

Figure 5-27 Bundling communications cables
Step 6 Tighten the thread-lock sealing nut and seal the waterproof connector.
----End
5.6.2.2 Connecting Cables to the RJ45 Network Port
RJ45 Connector Pin Denitions
Figure 5-28 shows an RJ45 connector.
Figure 5-28 RJ45 connector
Table 5-4 lists the RJ45 connector pin denitions.
Table 5-4 RJ45 connector pin denitions
Pin
Color Function
1 White-and-orange RS485A, dierential signal+
SUN2000-(70KTL, 75KTL)-C1
User Manual 5 Electrical Connections
Issue 09 (2020-10-12) Copyright © Huawei Technologies Co., Ltd. 57
