Huawei SUN2000 User Manual

SUN2000-(3.8KTL-11.4KTL)-USL0
User Manual
8 System Maintenance
Issue 01 (2018-05-21)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
137
Figure 8-3 Removing the 2-pin enable terminal
Step 3 Remove the USB cable (optional, only for the 4G model), or remove the WLAN cable
(optional, only for the WLAN model).
Do not remove the 4G module when removing the USB cable.
Figure 8-4 Removing the USB cable (optional, only for the 4G model)

Huawei SUN2000 Specifications

General

Model	SUN2000
Efficiency	Up to 98.6%
MPPT	Yes
Max Input Voltage	1100V
Number of MPPTs	2
Operating Temperature	-25°C to +60°C
Protection Level	IP65
Communication	RS485
Nominal Output Voltage	230V/400V
