Ensure that AC terminations are secured. Failure to do so may cause the SUN2000 to
malfunction or cause damage to its terminal block due to issues such as overheating. Any
such damage is not covered by the warranty.
The cable colors shown in the following figures are for reference only. Select an
appropriate cable according to local standards.
Figure 5-11 SUN2000-3.8KTL/5KTL/7.6KTL-USL0
To Next Page
