Huawei UAP2105 - Technical Specifications of the UAP2105; Table 3-4 Technical Specifications of the UAP2105

Item Specification
Service
capabilities
Common PS and CS services:
l A maximum of four concurrent AMR services is supported.
l A maximum of four concurrent VP services is supported.
l A maximum of eight concurrent PS services is supported.
l A maximum of four concurrent R99 384 kbit/s PS services is
supported.
l A maximum of four concurrent CS users is supported.
l A maximum of four concurrent PS users is supported.
HSDPA service:
l The maximum supported HSDPA rate is 3.6 Mbit/s or 7.2 Mbit/s. The
default value is 3.6 Mbit/s. The license can be used to control the
maximum HSDPA rate of the UAP2105.
l 3GPP R99, R4, R5, and R6 services can be provided at the same time.
l A maximum of four concurrent HSDPA users is supported.
l A maximum of 10 HS-PDSCH codes is supported.
HSUPA service
l The maximum supported HSUPA rate is 1.44 Mbit/s.
l 3GPP R99, R4, R5, and R6 services can be provided at the same time.
l A maximum of four concurrent HSUPA users is supported.
l The 10 ms Transmission Time Interval (TTI) over the E-DCH is
supported.
Transmit and
receive diversity
No transmit diversity or receive diversity
Receiver
sensitivity
-110 dBm
Clock precision ±0.1 ppm
3.4.2 Technical Specifications of the UAP2105
This describes the technical specifications of the UAP2105.
Technical Specifications
Table 3-4 Technical specifications of the UAP2105
Item
Specification
Dimensions (Height x Width x Depth) 33 mm x 125 mm x 125 mm
Weight 0.4 kg
3 Introduction to the UAP2105
UAP2105
User Guide
3-6 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2009-08-20)
