If Status of the FTP Server is ... Then …
Unavailable The AP Manager cannot communicate with
the FTP server normally.
l Select the option button before the FTP
server, and then click Modify. Configure
the FTP server on the displayed File
Server Information page.
Procedure
Step 1 Log in to the AP Manager, choose Fault > Terminal Files, and then click Uploading Files.
Step 2 The Uploading Files page is displayed. On the page, type the APEI of the AP whose terminal
files need to be uploaded in the Serial NO. box and select a target file from the File Type drop-
down list.
The types of the AP terminal files to be uploaded are as follows:
l Configuration File
l Performance File
l Alarm Log
Alarm logs consist of CurrUserAlm.log, HisUserAlm.log, and OrigAlm.log. The AP saves
a maximum of 10,000 OrigAlm.log entries, 50 CurrUserAlm.log entries, and 1,000
HisUserAlm.log entries. After the number of saved entries reaches the threshold, the earliest
entries are deleted so that follow-up entries can be saved.
l Running Log
The AP saves a maximum of 2,000 running log entries. After the number of saved entries
reaches 2,000, the earliest entries are deleted so that follow-up entries can be saved.
l Core Log
The latest three core log entries for abnormal resetting of the AP are saved.
Step 3 Click Uploading Files to upload the specified terminal files of the AP.
If ...
Then …
View Files is displayed Click View Files. In the File List pane, Status indicates
the uploading status of the file.
View Files is not displayed, or a
message box is displayed
The connection to the FTP server through the AP
Manager is faulty. Choose System > System Setting >
Fault, and then reset the login information of the FTP
server.
