Huawei WS319 User Manual

46
10 Appendix
Technical Specifications
Item Specifications
Power supply
12 V DC，0.5 A
Power consumption < 3.5 W
Ambient operating
temperature
0°C to 40°C
Ambient humidity 5% to 95% RH (non-condensing)
Dimensions (H x W x D) 32 mm x 160 mm x 110 mm (1.26 in. x 6.30 in. x 4.33 in.),
antenna excluded
Weight About 360 g
WLAN standard 802.11b, 802.11g, 802.11n (2.4GHz)
Wireless transmission
rate(2.4G)
802.11b Up to 11 Mbit/s
802.11g Up to 54 Mbit/s
802.11n (2T2R
antenna
technology)
Up to 300 Mbit/s
Default Settings
Parameter Default Value
LAN port IP address 192.168.3.1
LAN port subnet mask 255.255.255.0
User name to log in to the web
configuration page
admin
Password to log in to the web
configuration page
admin
WLAN name Labeled on the product cover
WLAN password Labeled on the product cover

Huawei WS319 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	-
Ethernet LAN (RJ-45) ports	4
Antennas quantity	2
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	Black

Weight and Dimensions

Weight	176 g
