A – LCD Display
1. Run Times – Allows user to set each valve station run time
from 1 minute to 4 hours.
2. Start Times – Allows 1 to 4 start times to be set in each
program.
3. Station Number – Indicates currently selected station number.
4. Program Designator – Identifies program in use A, B, or C.
5. Day of the Week – Identifies day of the week (-E models will be
indicated by number 1 to 7)
6. Flashing Sprinkler – Indicates that watering is occurring.
7. System Off – Allows user to discontinue all programs and
stop all watering. Also allows the user to set the controller to a
timed off until dial is returned to the Automatic position.
8.
Umbrella – Indicates Rain Sensor is suspending irrigation.
9.
Seasonal Adjustment – Allows user to make run time changes
according to the seasons without reprogramming. Bars on the left
indicate seasonal adjustment percentage.
10.
Rain Drop – Indicates watering will occur on that selected day.
11.
Crossed Rain Drop – Indicates watering will NOT occur on
selected day.
12. Calendar – Indicates interval watering schedule is being
programmed.
B – Wiring Compartment
13. 9-Volt Battery Connector – The alkaline battery can be used to
program the controller in the absence of AC power. Even without a
9-volt battery the EC will keep track of time for up to 1 month and
retain the program indefinitely in the event of a power outage.
14. Battery Compartment – Compartment for the 9-volt battery.
15. Terminal Strip Area – Use to attach transformer and valve wires
from their source to the controller.
16. Reset Button – Use to reset the controller.
17. Conduit Cover – Covers the field wires as they exit the conduit
into the bottom of the controller.
C – Control Buttons
Button – Increases the selected flashing display.
Button – Decreases the selected flashing display.
Button – Advances the selected flashing display to the next item.
Button – Selects program A, B or C for different watering zone
requirements.
Dial Settings
Automatic – Normal dial position for all controller automatic and
manual operation.
Current Time/Day – Allows current day and clock time to be set.
Start Times – Allows 1 to 4 start times to be set in each
program.
Run Times – Allows user to set each valve station run time from 1
minute to 4 hours.
Water Days – Allows user to select individual days to water or a
selected number of days between waterings (interval).
Seasonal Adjustment – Allows user to make run time changes
according to the seasons without reprogramming. Bars on the left
indicate seasonal adjustment percentage.
Manual-One Station – Allows user to activate a one time watering
of a single valve station.
Manual-All Stations – Allows user to activate a one time watering
of all valve stations or a few selected stations.
System Off – Allows user to discontinue all programs and stop all
watering. Also allows the user to set the controller to a timed off
until dial is returned to the Automatic position.
D – External Transformer (Indoor Model only)
A plug in transformer is provided to supply AC power to the controller.
2
