17
Connecting a Hunter Remote (continued)
NOTE
Any extension of the wiring on the SmartPort
®
may result in an
error message in the controller display and possible malfunction
of the remote unit due to radio interference. In some situations,
lengthening of the harness may work fine, in others it may not
work at all (it is site specific). In either case, extending the wiring
harness should be done using shielded cable to minimize the
possible effects of electrical noise. For easiest installation,
order the Hunter SmartPort shielded cable wiring harness
(P/N ROAM-SCWH) with a full 25' (7.6 meters) of
shielded cable.
12” / 30cm
REM
(Blue)
AC2
(White)
AC1
(Red)
To Next Page
