Pro-C Components (continued)
①
Main Display
Indicates various times, values,
and programmed information
②
Year Identies current calendar year
③
Month Identies current calendar month
④
Day Identies current calendar day
⑤
Start Time
Identies selected program
start time
⑥
Program Selector
Identies the program in use:
A, B, or C
⑦
Station Number
Identies currently selected
station number
⑧
Run Time
Allows user to set each valve
station run time from 1 minute
to 4 hours
⑨
Days of the Week
Identies days of the week
to water or not water
⑩
Odd/Even Watering
Identies if odd or even
watering days are selected
⑪
Interval
Identies if interval watering
has been selected
⑫
Seasonal Adjustment
Displays in increments of 5%,
the percentage of seasonal adjust
that has been selected
Running
Sprinkler icon indicates when
watering is occurring
Rain Drop
Indicates watering will occur on
selected day
Crossed Rain Drop
Indicates watering will NOT occur
on selected day
A
LCD Display
B
Control Buttons and Switches
⑬
j Button
Increases the selected
ashing display
⑭
k Button
Decreases the selected
ashing display
⑮
i Button
Advances the selected ashing
display to the next item, also use to
start a manual cycle
⑯
h Button
Returns selected ashing display to
the previous item
⑰
n Button
Selects programs A, B, and C;
also to start a test program
⑱
Rain Sensor
Bypass Switch
Use to bypass weather “Clik-type”
sensors if one is installed
