7
Pro-C Components (continued)
C
Control Dial
①
Run
Normal dial position for
automatic operation
②
Set Current Date/
Time
Set current date and time
③
Set Program
Start Times
Set 1 to 4 start times in each
program
④
Set Station Run Times Set each station run time
⑤
Set Days to Water
Select individual days to water,
odd, even or interval watering
schedule
⑥
Set Pump Operation
Turn pump or master valve
on or o for each station
⑦
Seasonal Adjustment
Make global run time changes
without programming the
controller (from 5% to 300%)
⑧
Solar Sync
®
Allows user to program settings
when using Solar Sync ET sensor
⑨
Manual—Single
Station
Activates a one time watering of
a single station
⑩
System O
Used to discontinue all programs
and stop all watering until the dial
is returned to the RUN position,
or to set the programmable rain
o feature
D
Wiring Compartment
①
9-Volt Battery
An alkaline battery (not included) allows
programming of the controller without
AC power
②
Reset Button
This button will reset the controller.
All programmed data will remain intact
③
Power Area
Used to attach transformer, sensor wires,
and other systems to the controller
④
Sensor Terminals
Used to connect Hunter Solar Sync or
“Clik-type” sensors
⑤
Transformer
A transformer is installed (Outdoor
models only, indoor models are supplied
with a plug-in transformer)
⑥
Junction Box
This box provides an area for connecting
primary AC power (Outdoor models only)
⑦
SmartPort
®
Input Terminals
Used to connect a SmartPort, which
enables Hunter remote controls
⑧
Ground Lug
For additional surge protection, connect
lug to earth ground
To Next Page
