ROAM XL COMPONENTS
This section will give you a brief description of the
components that make up the ROAM XL. Each item
will be discussed in further detail later. However, this
section can be helpful in getting acquainted with the
Transmitter, Receiver, and SmartPort
®
.
TRANSMITTER
A. LCD Display
1. Run Time – Indicates the station run time is
being set.
2. Transmit – Indicates that the transmitter is
transmitting the programmed data to the receiver.
3. Max Station Number – Indicates station
number (1–48 Residential, 1–240 Commercial).
On – Indicates Transmitter is turning on the
selected station or program.
Off – Indicates transmitter is turning off any
running station or program.
PA, PB, PC – Indicates program selected.
P1, P2... – Demonstrates differences between
residential programs and commercial programs.
4.
Address – Indicates that a new address for
transmitting between the Transmitter and the
Receiver is being set.
5. Battery – Indicates how much battery power
is left.
B. Control Buttons
6.
– Increases the selected functions.
7. – Decreases the selected functions.
