Hunter Soil-Clik - Pcc; Pro-C

16
GND
AC1 AC2
REM
SEN SEN
SEN
SEN
AC2
AC1
GND
Connecting the Module to Hunter Products
PCC Pro-C®
1. Yellow power wires to the PCC AC1 and
AC2 power terminals
2. White wires to the SEN sensor terminals
3. Or use the Common Interrupt method on
page 18
1. Yellow power wires to the Pro-C AC1 and
AC2 power terminals
2. White wires to the SEN sensor terminals
3. Or use the Common Interrupt method on
page 18
