Hunter Soil-Clik - Common Interrupt Wiring Method

COM 1 2 3 424V 24V
18
Common Interrupt (Most AC-Powered Controllers)
1. Connect Yellow power wires to 24V power in the
controller.
2. Cut eld common wire(s), and splice one Soil-Clik
white wire to each end of the common.
Connecting the Module to Hunter Products
Yellow
White
