HunterDouglas Luminette - Attach End Treatments to Swivel Plates

INSTALLATION
18
Attach the End Treatment(s) to the Swivel Plate(s)
■ Hold the end treatment near the swivel plate at a
height where the end vanes hang straight and the top
of the end treatment is approximately
1
/ 8 " above the
top of the swivel plate.
■ Attach the end treatment by pressing it onto the
swivel plate.
■ If the end treatment is not hanging straight, separate
the swivel plate from the end treatment and reposition
it. Separate the swivel plate by pulling up on the end
treatment while holding the swivel plate in place.
■ Re-attach the end treatment. Repeat the adjustment
as necessary.
Swivel
Plate
