INSTALLATION
5
■ Mark where to drill holes for the screws.
IMPORTANT: The front edges of the brackets must align to each other.
➤ Align the outside edge of the end
brackets on your marks, then mark
each of the screw holes. Center
additional brackets on the marks to
mark their screw holes.
➤ The minimum mounting depth required is 1".
➤ To fully recess the fabric in the window casement, the mounting depth required is 6
1
/
4
".
See the illustration below.
Bracket Headrail
Stacked
Fabric
Vane
6
1
/
4
" Minimum Fully Recessed Depth
Inside Mount
Fully Recessed Mounting Depth
Window
Side
1" Minimum
5"
To Next Page
