Pre-Installation Manual for i-Series Machines v387 Site Preparation 1-1
SITE PREPARATION
This manual provides instructions for tasks that should be completed prior to the machine
installation.
Machine Overview
The pictures below identify some of the easily recognized components of machines. The
location of some components may differ on other models.
Figure 1–1. Turning Center with Max Console
Figure 1–2. Machining Center with dual-screen console
1. Max Console
2. Turret
3. Conveyor option
4. Coolant Drip Tray
5. Enclosure Door
6. Spindle
7. Tailstock/Chuck Gauge
options
8. Tailstock/Chuck
Footswitch options
1. Dual-screen Console
2. Machining Table
3. Chip Conveyor
4. Enclosure Doors
5. Spindle
6. Automatic Tool Changer
7. Coolant Gun
8. Air Gun
