TECHNICAL SPECIFICATIONS - ENGINE
I
4
TIGHTENING TORQUES
HH collar bolts on housing, clutch cover, ignition cover M6 10 Nm
Oil drain plug M12x1,5 20 Nm
HH plug oil screen M20x1,5 15 Nm
AH collar bolt on oil filter cover M5 6 Nm
Plug on pressure relief valve M12x1,5 20 Nm
HH bolts on oil pump cover M4 Loctite 243 + 5 Nm
HH collar bolt on cylinder head top section M6 10 Nm
AH bolts on valve cover M5 6 Nm
HH collar bolts on water pump cover M6 10 Nm
HH bolts on cylinder head M10 50 Nm
HH bolt on cylinder head M6 10 Nm
AH bolts on camshaft gear M8 Loctite 243 + 28 Nm
HH nut on automatic decompression stop M5 Loctite 2701 + 8 Nm
AH bolts on rocker arm shaft silencer cap M5 Loctite 243 + 6 Nm
Counternut on valve adjusting screw M6x0,75 11 Nm
HH nut on primary pinion M16x1 Loctite 2701 + 110 Nm
HH nut on idler shaft gear M16x1 Loctite 2701 + 110 Nm
HH nut on clutch drive M18x1,5 Loctite 243 + 120 Nm
HH collar bolts on clutch springs M6 Loctite 243 + 8 Nm
HH bolt shift on shift roller lock M6 Loctite 243 + 10 Nm
HH collar bolt on locking lever M6 Loctite 243 + 10 Nm
HH collar bolt on shift roller bearing M6 Loctite 243 + 10 Nm
HH collar bolts on chain tensioner M6 10 Nm
HH bolt chain tensioning rail M5 Loctite 243 + 6 Nm
HH bolt on chain guide rail M6 Loctite 243 + 6 Nm
HH collar bolts on stator FE/FS models M6 Loctite 243 + 10 Nm
HH collar bolts on stator FC models M5 Loctite 243 + 6 Nm
HH collar bolts on pulse generator M5 Loctite 243 + 6 Nm
HH collar nut on rotor M12x1 60 Nm
HH collar bolt on starter cap, FC models only M6 10 Nm
HH bolt on kickstarter M6 Loctite 243 + 10 Nm
Kickstarter release plate M5 Loctite 243 + 6 Nm
HH collar bolt on shift lever M6 10 Nm
Spark plug M12x1,25 20 Nm
Plug on engine blocking bore M8 20 Nm
Diaphragm valve M4 Loctite 243 + 1,5 Nm
