CHANGING THE ENGINE OIL
NOTE: Replace the oil screen and the oil filter
when you change the engine oil.
Change the engine oil when the engine is at
operating temperature.
WARNING: the engine oil will be very hot when
the engine is at operating temperature – be
careful not to burn yourself.
Place the motorcycle on a level surface, remove the
plug (1) and allow the oil to drain into a suitable vessel.
Thoroughly clean the plug (with the magnet).
After the oil is completely drained, clean the sealing
area, mount the plug with a new seal ring and tighten
to 20 Nm.
CLEANING THE OIL SCREEN
NOTE: the oil screen (3) is located in the plug
with the hexagon drive (2) next to the oil drain
plug on the right side of the engine.
–Dismount the plug with the oil screen, thoroughly
clean the parts and blow clean with compressed air.
Check the O-rings (4) for damage and replace if
necessary.
Insert the oil screen in the plug, mount and tighten the
plug to 15 Nm.
GENERAL INFORMATION
A
2
1
2
3
4
4

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HUSABERG FE 450 and is the answer not in the manual?

HUSABERG FE 450 Specifications

General IconGeneral
Engine TypeSingle cylinder, 4-stroke
Displacement449.3 cc
Bore x Stroke95 mm x 63.4 mm
Compression Ratio11.8:1
StarterElectric starter
Transmission6-speed
LubricationPressure lubrication with 2 oil pumps
CoolingLiquid cooling
Fuel SystemKeihin EFI
IgnitionDigital CDI
