GENERAL INFORMATION
A
7
FIG PART NUMBER DESCRIPTION
1 560.12.001.000 Universal engine work stand
2 800.29.002.000 Engine holder for universal engine work stand
3 309098 Silicone three bond sealing compound
46 899 785 Loctite 243 blue 10 ml
800.29.059.000 Loctite 2701 green 10 ml
5 503.29.050.000 Bleeder syringe for hydraulic clutch
6 590.29.041.000 Feeler gauge for valve clearance
7 590.29.072.000 16 mm spark plug wrench
8 580.30.080.000 Locking bolt
9 590.29.019.000 Valve lifter
10 510.12.011.000 Circlip pliers inverted
11 600.29.015.000 Piston ring clamp
12 590.29.026.006 6 mm limit plug gauge for valve guide
13 580.12.009.000 Rotor extractor
14 800.29.030.000 Timing chain riveting tool
15 590.29.033.000 Extractor for timing gear and camshaft bearing
16 584.29.037.037 Mounting tool for bearing inner rings on crankshaft
17 151.12.017.000 Bearing extractor
18 151.12.018.000 12-16 mm insert for bearing extractor
19 800.29.004.000 Gear segment
20 800.29.003.000 Clutch holder
21 800.29.020.000 Housing separating tool
22 800.29.031.000 Protection cover for crankshaft
23 590.29.005.010 Mounting sleeve for the shaft seal ring on the water pump
24 800.29.005.000
Mounting sleeve for the left shaft seal ring on the the crankshaft
800.29.105.000
Mounting sleeve for the right shaft seal ring on the crankshaft
800.29.205.000
Mounting sleeve for the shaft seal ring on the kickstarter shaft
25 800.29.035.000 Pressing tool for conrod bearing (out)
26 800.29.036.000 Pressing tool for conrod bearing (in)
27 800.29.052.000 Safety TORX TX20 for the carburetor potentiometer
SPECIAL TOOLS - ENGINE
